Breakthrough stacked Event-based Vision Sensor realized in collaboration between Sony and PROPHESEE
Sony IMX637 co-developed with Prophesee
1/4.5 inch format event-based vision sensor with approx 0.32 M effective pixels
KEY FEATURES
- Resolution (px): 640 x 512
- Optical format: 1/4.5”
- Pixel latency @ 1000 lux (μs): <100
- Pixel latency @ 5 lux (μs): <1000
- Size (mm): 13×13 (LGA package)
- Dynamic Range* (dB): >86 (5 lux – 100 klux) / >120 (80 mlux – 100klux)
- Maximum clock frequency (MHz): 100
- Max Power (Dynamic with ESP, MIPI output) (mW): 142
- Standby Power (mW): 2.2
- Pixel size (μm) 4.86 x 4.86
- Event Signal Processing embedded
*5 lux is the minimum light level guaranteeing inclusion of all possible operating points. Low-light cut-off is the minimum light level guaranteeing nominal contrast sensitivity. For many typical applications, the sensor data are actionable down to this light level. 100000 lux is a virtual high-light limit, not experienced in experiment.
Markets and applications
Industrial Automation
Safety zone monitoring
Scientific Measurement
VARIANTS AVAILABLE
COMPATIBLE PRODUCTS
ADVANCED TOOLKIT
With Evaluation Kits purchases comes complementary access to an advanced set of tools composed of a support portal, drivers, open-source platform, SDK, tutorials, reference data and much more.
We are sharing an advanced toolkit so you can start developing your own vision.
THE MOST COMPREHENSIVE EVENT-BASED VISION SOFTWARE SUITE
64 algorithms, 105 code samples and 17 tutorials in total to let you evaluate and design your own Metavision product.
SUPPORT RESOURCES
With USB EVK purchase, get access to 2 hours of onboarding support within the first 2 months, as well as our privileged Knowledge Center, including over 110 articles, application notes, in-depth technology discovery material and step-by-step guides.
OPEN SOURCE ARCHITECTURE
Metavision SDK is based on an open source architecture, unlocking full interoperability between our software and hardware devices and enabling a fast-growing Event-Based community.
EXTENSIVE DOCUMENTATION
With 300+ pages of regularly updated content on docs.prophesee.ai, programming guides, reference data, detailed recommendations, get a head start on your application development.
